Our Rigs

Our fleet consists of the following:

Cardium
Depth Ratings:	2200 – 3200m
Hook Load:	96,000- 138,000 daN
Circulating System:	5000 psi
Top Drive’s:	150 Ton
Pump Capacity:	1000-1300 hp

Cardium +
Depth Ratings:	3200-3600m
Hook Load:	172,000 daN
Circulating System:	5000 psi
Top Drive’s:	250 Ton
Pump Capacity:	1300 hp
Racking Capabilities:	3900-4900m

Montney
Depth Ratings:	4000-4500m
Hook Load:	178, 000-196, 000 daN
Circulating System:	5000-7500 psi
Top Drive’s:	250 Ton
Pump Capacity:	1300-1500 hp (2)
Racking Capabilities:	4600-6000m

Duvernay
Depth Ratings:	5000-6000m
Hook Load:	222, 000- 267, 000 daN
Circulating System:	7500 psi
Top Drive’s:	250-350 Ton
Pump Capacity:	1300-1600 hp (2)
Racking Capabilities:	4600-8000m

Rig Inventories

Rig #	Rig Class	Rig Type	Static Hookload (daN)	Racking Capacity	Pump Rating(hp)	Top Drive	Circulating System	Pad Rig	Dual Fuel	Smart Slide
Rig 2	Montney	Telescopic Double	185,000	6,000m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	Yes	Yes
Rig 3	Montney	Telescopic Double	185,000	4,500m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	No	Yes
Rig 4	Montney	Telescopic Double	196,000	6,000m of DS40	1,500 ✖ 1; 1,300 ✖ 1	Tesco 250-HXI-700	7,500 psi	Rig Only	No	Yes
Rig 5	Montney	Telescopic Double	196,000	6,000m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 7	Cardium	Telescopic Single	133,000	N/A	1,300 ✖ 1	Foremost F-150TA	3,000 psi	No	No	No
Rig 9	Cardium	Telescopic Single	133,000	N/A	1,300 ✖ 1	Foremost F-150TA	5,000 psi	No	No	No
Rig 11	Duvernay	Cantilever Triple	222,000	6,500m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 14	Montney	Telescopic Double	196,000	5,200m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	Rig Only	No	Yes
Rig 16	Cardium	Telescopic Single	133,000	N/A	1,300 ✖ 1	Foremost F-150T	5,000 psi	No	No	No
Rig 17	Cardium	Telescopic Single	133,000	N/A	1,300 ✖ 1	Foremost F-150T	5,000 psi	No	No	No
Rig 18	Cardium	Telescopic Single	133,000	N/A	1,300 ✖ 1	Foremost F-150T	5,000 psi	No	No	No
Rig 19	Montney	Telescopic Double	196,000	5,200m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	No	Yes
Rig 21	Montney	Telescopic Double	196,000	6,000m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 22	Montney	Telescopic Double	196,000	6,000m of DS40	1,500 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	Yes	Yes
Rig 23	Montney	Telescopic Double	196,000	6,000m of DS40	1,500 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 27	Cardium	Telescopic Double	167,000	4,900m of DS40	1,300 ✖ 1	Tesco 250-HXI-700	5,000 psi	No	No	No
Rig 29	Cardium	Telescopic Double	167,000	4,900m of DS40	1,000 ✖ 1	Tesco 250-HXI-700	5,000 psi	No	No	No
Rig 30	Montney	Telescopic Double	196,000	6,000m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	Yes	Yes
Rig 33	Cardium	Telescopic Double	172,800	4,400m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	No	Yes
Rig 34	Cardium	Telescopic Double	172,800	4,400m of DS40	1,300 ✖ 1	Tesco 250-HMI-475	5,000 psi	No	No	Yes
Rig 37	Montney	Telescopic Double	196,000	5,200m of DS40	1,500 ✖ 1; 1,300 ✖ 1	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 39	Cardium	Telescopic Double	167,000	4,900m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	No	Yes
Rig 41	Montney	Telescopic Double	196,000	6,000m of DS40	1,500 ✖ 1; 1,300 ✖ 1	Tesco 250-HXI-700	7,500 psi	Rig Only	No	Yes
Rig 43	Montney	Telescopic Double	196,000	5,900m of DS40	1,500 ✖ 1; 1,300 ✖ 1	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 44	Montney	Telescopic Double	178,000	5,200m of DS40	1,000 ✖ 1	Tesco 250-HXI-700	5,000 psi	No	No	No
Rig 45	Montney	Telescopic Double	178,000	5,200m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	No	Yes	No
Rig 46	Duvernay	Telescopic Double	222,000	6,000m of DS40	1,500 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 48	Duvernay	Telescopic Double	222,000	6,000m of DS40	1,500 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	No	Yes
Rig 50	Montney	Telescopic Double	178,000	5,100m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	7,500 psi	No	Yes	Yes
Rig 51	Montney	Telescopic Double	196,000	5,200m of DS40	1,300 ✖ 2	Tesco 250-HXI-700	5,000 psi	Yes	No	Yes
Rig 52	Montney	Telescopic Double	196,000	5,900m of DS40	1,300 ✖ 2	Canrig 6027AC	7,500 psi	Yes	Yes	Rockit
Rig 55	Duvernay	Telescopic Triple	267,000	8,050m of DS40	1,600 ✖ 2	Tesco 350-EXI-600	7,500 psi	Yes	No	ACE System
Rig 61	Cardium	Telescopic Single	96,000	N/A	1,000 ✖ 1	FDS 150	5,000 psi	No	No	No

Other available options:
